Loaded deck height/clearance: 18 inches with 6 inches ground clearance
Flooring: 2 inch nominal wood - side rails only
Axles
Standard trailer axles: 3
25,000 lb. nominal capacity per axle NOTE: GAWR determined by suspension type, brakes, tires and other components.
Axle spread: 54.5 inches (between axles)
Bogie
Deck to bogie
connection: Fixed
Rear bogie height: 40 7/8 inches to top flange - 36 5/8 inches to top of bolsters
Tires
Tire size: 275/70R 22.5 OEM standard
Weight
Estimated weight from 22,040 lbs. ±3%
Standard Features
Framework: All main longitudinal members fabricated with 100,000# minimum yield steel flanges with 50,000# webs
Loaded Fifth Wheel Height: 50 inches nominal; Dual Cam Pawl Arm Assembly with 7 ride height positions
Kingpin: Removable kingpin at 108 inch radius
Alternate Kingpin: Alternate Kinpin location at 89 inch radius
Power Source:
Set up for wet line operation
Electrical Receptacle: J560 7-pin connector
Front Ramps: Manual front approach ramps included
Front Bogie Ramp: Included as standard
Extension Brackets: 13 pair - 26 total removable swing type, 2 pair - 4 total heavy duty removable hook-on type (26 swing type, 4 hook-on type on 27 foot deck)
Tool Box: 2 Fully covered trays in front of deck between mainbeams with lockable covers.
Crossmembers: Recess last 3 crossmembers in deck
Hammer Plate: Hammer Plate (16in x 60in x 1/2 in) installed over recessed crossmembers. Preforated plate under hammer plate
Brakes: 16.5 inches x 7 inches with 5.5 inches autoslacks - heavy duty brake drums - outboard mount
Suspension: Air ride
Lift Axle: Air lift 3rd axle
Wheels:
8.25 x 22.5 steel disc - hub-piloted
Bolsters: Recessed load bearing between all axles and rear of last axle
Boom Trough: V-style boom trough with bolt-in V pan
Ride Height Control: 5-position mechanical ride height control system
Manual Dump Valve: Installed
Bumper: Heavy duty V-style bumper
Electrical System: DOT sealed beam and harness with LED lights and 4 inch flush mounted battery powered amber strobes
Lash Rings: 19 pair, 38 total
Flag Holders: Flag holders - 2 pair located at front of deck and rear bumper
